How-To Guides
Specifications
Model Number
GK-Z001
Engine/Drive Train
Engine
49cc, 4 st...
How-To Guides
Specifications
Model Number
GK-Z001
Engine/Drive Train
Engine
49cc, 4 stroke
Cylinder Arrangement
Single
Cooling System
Air Cooled
Power Output
1.4KW at 7000rpm
Torque
2.5NM at 4500rpm
Max Speed (MPH)
12.5+ (Depending on Riders Weight and Road Conditions)
Start System
Manual-hand Pull Type
Frame /Body/ Suspension / Brakes
Frame
Welder high strong steel tubes
Rear Brake
Disc
Front Tires
4.10-6
Rear Tires
13x5-6
Capacities / Dimensions
Max Weig...
How-To Guides
Specifications
Model Number
GK-W017
Engine/Drive Train
Engine
110cc, 4 s...
How-To Guides
Specifications
Model Number
GK-W017
Engine/Drive Train
Engine
110cc, 4 stroke
Cylinder Arrangement
Single
Cooling System
Air Cooled
Transmission
Fully Automatic with Reverse
Reverse Gear
Yes
Carburetor Brand
PZ19
Bore*Stroke
1.5*1.6"
Max Speed (MPH)
30+ (Depending on Riders Weight and Road Conditions)
Final Drive
Chain Drive, Rear wheel drive
Start System
Electric
Ignition
CDI
Battery
12V/5Ah
Frame /Body/ Suspension / Brakes
Front Brakes
None...
How-To Guides
Specifications
Model Number
GK-U03
Engine/Drive Train
Engine
Zongshen Br...
How-To Guides
Specifications
Model Number
GK-U03
Engine/Drive Train
Engine
Zongshen Brand 125cc, 4 stroke, 1-cylinder
Cooling System
Air Cooled
Max Horsepower
5.9KW/7500r/min
Max Torque
9.5N.m/5500r/min
Bore Stroke
54x54
Compression Ratio
9.0:1
Transmission
Semi-Automatic with Reverse
Max Speed (MPH)
35+ (Depending on Riders Weight and Road Conditions)
Final Drive
Rear Chain Drive
Start System
Electric
Carburetor
PZ22
Ignition
CDI
Battery
12V/5Ah
Frame /Bo...
How-To Guides
Specifications
Model Number
GK-U02
Engine/Drive Train
Engine
Zongshen Br...
How-To Guides
Specifications
Model Number
GK-U02
Engine/Drive Train
Engine
Zongshen Brand 125cc, 4 stroke, 1-cylinder
Cooling System
Air Cooled
Max Horsepower
5.9KW/7500r/min
Max Torque
9.5N.m/5500r/min
Bore Stroke
54x54
Compression Ratio
9.0:1
Transmission
Semi-Automatic (1 Reverse + N + 3-speed)
Max Speed (MPH)
35+ (Depending on Riders Weight and Road Conditions)
Final Drive
Rear Chain Drive
Start System
Electric
Carburetor
PZ22
Ignition
CDI
Battery
12V/5A...
How-To Guides
Specifications
Model Number
GK-U04
Engine/Drive Train
Engine
Zongshen Br...
How-To Guides
Specifications
Model Number
GK-U04
Engine/Drive Train
Engine
Zongshen Brand 125cc, 4 stroke, 1-cylinder
Cooling System
Air Cooled
Max Horsepower
5.9KW/7500r/min
Max Torque
9.5N.m/5500r/min
Bore Stroke
54x54
Compression Ratio
9.0:1
Transmission
Semi-Automatic with Reverse
Max Speed (MPH)
35+ (Depending on Riders Weight and Road Conditions)
Final Drive
Rear Chain Drive
Start System
Electric
Carburetor
PZ22
Ignition
CDI
Battery
12V/5Ah
Frame /Bo...
How-To Guides
Specifications
Model Number
GK-F031
Engine/Drive Train
Engine
119.6cc, ...
How-To Guides
Specifications
Model Number
GK-F031
Engine/Drive Train
Engine
119.6cc, 4 stroke
Cylinder Arrangement
Single
Engine Type
152FMI
Max Power
5.8Kw/7500rpm
Max Torque
7.7Nm/6000rpm
Compression Ratio
9.6:1
Bore x Stroke
52.4×55.5
Cooling System
Air Cooled
Transmission
Automatic
Reverse Gear
Yes
Final Drive
Chain Drive
Start System
Electric
Ignition
CDI
Max Speed (MPH)
35+ (Depending on Riders Weight and Road Conditions)
Battery
12V/9Ah
Frame ...
How-To Guides
Specifications
Model Number
GK-H01
Engine/Drive Train
Engine
119.6cc, 4 ...
How-To Guides
Specifications
Model Number
GK-H01
Engine/Drive Train
Engine
119.6cc, 4 stroke
Cylinder Arrangement
Single
Cooling System
Air Cooled
Compression Ratio
9.6:1
Bore x Stroke
52.4X55.5
Max Power
5.3Kw/7000rpm
Max Torque
8.5Nm/5000rpm
Transmission
Automatic
Reverse Gear
Yes
Final Drive
Chain Drive
Start System
Electric
Ignition
CDI
Max Speed (MPH)
30+ (Depending on Riders Weight and Road Conditions)
Battery
12V/6.5Ah
Frame /Body/ Suspension / B...
Description
CARB Information
This bike is not legal for sale in California.
Assembly
Assembly fo...
Description
CARB Information
This bike is not legal for sale in California.
Assembly
Assembly for MOST Go Karts includes: All four wheels, rear shock, gas tank, roll cage bars, steering wheel, seats, gas lines and battery (may differ per model)
Key Features
New Upgraded X-PRO 125cc Go Kart. Main Features:
Free Upgraded 125cc Powerful Zongshen Engine: The engine is located under the seat (the most central position of the cart), makes the gokart remains stable during driving. The distanc...
