Free Shipping! X-PRO Storm DLX 150 Dirt Bike with All Lights, 4-Speed Manual Transmission, Electric/Kick Start, Big 19in/16in Tires!
Description
CARB Information
This bike is not legal for sale in California.
Assembly
Assembly for MOST dirt bikes includes: Handle bar brackets (c-clamps), front wheel, front brake, number plate and front fender. (May differ per model)
Key Features
New Upgraded X-PRO Storm DLX 150 Dirt Bike. Main Features:
- Free Upgraded 145cc Oil Cooled Engine: The main purpose of using an Oil Cooler is to keep the engine cool from overheating. It is largely useful and usable viscosity. The installation of the oil cooler will protect your bike from long-term damages and extend the engine life.
- Free upgraded Inverted Front Shock: more responsive to road conditions, stronger anti-twist ability.
- Free Upgraded Perimeter Cradle Type Steel Frame($150 value): with greater strength and rigidity, and better stability during frequent acceleration and braking.
- Free Upgraded Better Quality Muffler ($100 value): Reduce engine exhaust noise and enable high-temperature exhaust gas to be discharged safely and effectively!
- Free Upgraded Headlight, Tail Light, Turn Signal Indicator($100 value)
- FAST!! 145cc 4 Stroke, Single Cylinder, Oil Cooled Engine.
- 4-Speed Manual Transmission Take fully control of the dirt bike, Pro's Choice!
- Electric/Kick start: Electric start for easy starting well the kick start is being used as a back up plan in any unexpected situations.
- Front and Rear Disc Brake Powerful and durable disc provides excellent braking at any speed; giving you the safety you need.
- Perimeter Cradle Type Steel Frame: more lighter and stronger with a longer service life, and making big jumps can be much easier.
- Wheel: 19" Front and 16" Rear Tire Higher and Longer, Fits for Adults and Big Boys!
- #428 Chain, 14T/41T: Heavy Duty Chain and Performance Sprocket
- Quality Oversized Foot Pegs
- The CDI Ignition Better performance and easier to start for optimal use.
- 6L Fuel Tank
- Off Road Use Only
- Some assembly required
Specifications
| Model Number | DB-K016 |
| Engine/Drive Train | |
|---|---|
| Engine | 145cc, 4 stroke |
| Cylinder Arrangement | Single |
| Cooling System | Oil Cooled |
| Compression Ratio | 9.0:1 |
| Bore x Stroke | Ф56.5×57.8mm |
| Max Power[Kw/r/m] | 6.8/7500±500 kw/r/min |
| Max Torque[N.m/r/m] | 11/5500±500N.m/r/min |
| Transmission | 4-Speed Manual |
| Final Drive | #428 chain, 14T/41T |
| Start System | Kich & E-start |
| Carburetor | PZ27 |
| Ignition | CDI |
| Max Speed (MPH) | 65+ (Depending on Riders Weight and Road Conditions) |
| Battery | 12V/4Ah |
| Frame /Body/ Suspension / Brakes | |
| Frame | Perimeter Cradle Type Steel Frame |
| Front Suspension | Inverted Hydraulic Forks, Φ45*Φ48-780mm |
| Rear Suspension | None-Adjustable Shock, 12*315mm |
| Front Brakes | Hydraulic Dual Piston Caliper, 220mm Disc |
| Rear Brakes | Hydraulic Single Piston Caliper, 190mm Disc |
| Front Tires | 70/100-19 |
| Rear Tires | 90/100-16 |
| Exhaust/Pipe | Stainless Steel Header Pipe & Silencer |
| Capacities / Dimensions | |
| Weight Capacity (lbs) | 176 |
| Net Weight (lbs) | 181 |
| Gross Weight (lbs) | 212 |
| Overall Length | 76.9" |
| Overall Width | 31.5" |
| Overall Height | 49.6" |
| Carton dimension (L*W*H/in) | 66 x 18 x 31" |
| Seat Height | 35" |
| Wheelbase | 52.8" |
| Ground Clearance | 12.6" |
| Fuel Capacity | 6L |
| Safety / Control | |
| Engine Kill Switch | Yes |
| Foot Brake | Yes |
| Headlights | Yes |
| Tail Lights | Yes |
| Turn Signal Indicator | Yes |
| Horn | Yes |
| Others | |
| EPA Approved | Yes |
|
|
|
Gallery
Different Colors
Different Angles
How-To Guides
Assembly Video
